特點(diǎn)：Metal package Clock Resonator
Excellent Shock and Heat resistance
Higher frequency stability and reliability
Reasonable price,
|
| |
|
|
| Item |
Specification |
| Frequency Range |
30KHz ~ 100KHz |
| Frequency Tolerance (at 25 ℃) |
±10ppm,±20ppm, ±30ppm,or specify |
| Frquency Stability Over Operating Temperature Range |
±50ppm Max |
| Operating Temperature Range |
-10 ~ +60℃ standard, -40 ~ +85℃ extended |
| Shunt Capacitance |
2.0pf Max |
| Load Capacitance |
Series, 6pf ~12.5pf |
| Drive Level |
3μW Max |
| Storage Temperature Range |
-20 ~ +70℃ |
| Aging |
± 5ppm / year Max | |
| Resistance of Series Resonance(ESR) |
| Frequency (MHZ) |
Mode |
ohm Max |
Frequency (MHZ) |
Mode |
ohm Max |
| 30.000 |
Fundamental |
50K |
33.000~60.000 |
Fundamental |
40K |
| 32.768 |
Fundamental |
50K |
60.001~100.000 |
Fundamental |
35K | |
|
|
|
|
